Streaming 1080P video using Raspberry Pi (or BeagleBone Black)

datePosted on 21:24, November 9th, 2013 by Many Ayromlou

I’ve finally got this project to a point were I can do a write up on it. The following hardware is needed:

  1. Raspberry Pi 512K version (or BeagleBone Black)
  2. Logitech C920 Webcam
  3. 16 GB micro SDHC card (can probably do it on 8GB too)
  4. Wireless dongle supported by linux (I’m using a TrendNet TEW-645UB which was pretty much plug and play)

The goal of this project is to get the following installed and configured:

  1. CRTMP streaming server
  2. C920 install and config (v4l2), ffmpeg installation, boneCV installation from Derek Molloy’s site
  3. configuring ddclient for dynamic DNS (optional)
  4. putting it all together and creating a webpage with embedded JWplayer to view the stream

UPDATE: Sound works now on BeagleBone Black. On Raspberry you will run into alsa buffer xruns. See below for updated streamVideoRTSP script.

What I still need to figure out is the sound off the camera. At the moment I got buttery smooth 1080P video off the Pi (on wired or wireless connection) running at 5Mb/s but the sound is yet to come.

0) Preparation:

So to prepare you need to get linux installed on your Pi or BBB (BeagleBone Black). I used the latest raspbian for the PI and BeageBone Black Ubuntu Raring 13.04 for BBB. Get it installed onto your SD card. If you use a larger than 8GB SD card you can follow the procedure below to expand the partition from 8GB to whatever your SD card can hold (mine is a 16GB card) (NOTE: almost all commands need to be executed as root so do a sudo -i to start with):

  • Use fdisk to see the partition table
    [email protected]:/# fdisk /dev/mmcblk0

    Command (m for help): p

    Disk /dev/mmcblk0: 3947 MB, 3947888640 bytes
    4 heads, 16 sectors/track, 120480 cylinders, total 7710720 sectors
    Units = sectors of 1 * 512 = 512 bytes
    Sector size (logical/physical): 512 bytes / 512 bytes
    I/O size (minimum/optimal): 512 bytes / 512 bytes
    Disk identifier: 0x80000000

            Device Boot      Start         End      Blocks   Id  System
    /dev/mmcblk0p1   *        2048        4095        1024    1  FAT12
    /dev/mmcblk0p2            4096     3751935     1873920   83  Linux
  • In this case we’re expanding partition 2 by first deleting it and without writing the partition table recreating it to span the entire disk (and then writing the new partition table to SD card). This in effect expands the partition. We will expand the filesystem after reboot.
    Command (m for help): d
    Partition number (1-4): 2

    Command (m for help): p

    Disk /dev/mmcblk0: 3947 MB, 3947888640 bytes
    4 heads, 16 sectors/track, 120480 cylinders, total 7710720 sectors
    Units = sectors of 1 * 512 = 512 bytes
    Sector size (logical/physical): 512 bytes / 512 bytes
    I/O size (minimum/optimal): 512 bytes / 512 bytes
    Disk identifier: 0x80000000

            Device Boot      Start         End      Blocks   Id  System
    /dev/mmcblk0p1   *        2048        4095        1024    1  FAT12

    Command (m for help):
    Command (m for help): n
    Partition type:
       p   primary (1 primary, 0 extended, 3 free)
       e   extended
    Select (default p): p
    Partition number (1-4, default 2): 2
    First sector (4096-7710719, default 4096):
    Using default value 4096
    Last sector, +sectors or +size{K,M,G} (4096-7710719, default 7710719):
    Using default value 7710719

    Command (m for help): p

    Disk /dev/mmcblk0: 3947 MB, 3947888640 bytes
    4 heads, 16 sectors/track, 120480 cylinders, total 7710720 sectors
    Units = sectors of 1 * 512 = 512 bytes
    Sector size (logical/physical): 512 bytes / 512 bytes
    I/O size (minimum/optimal): 512 bytes / 512 bytes
    Disk identifier: 0x80000000

            Device Boot      Start         End      Blocks   Id  System
    /dev/mmcblk0p1   *        2048        4095        1024    1  FAT12
    /dev/mmcblk0p2            4096     7710719     3853312   83  Linux

    Command (m for help):
    Command (m for help): w

    The partition table has been altered!

    Calling ioctl() to re-read partition table.

    WARNING: Re-reading the partition table failed with error 16: Device or resource busy.
    The kernel still uses the old table. The new table will be used at
    the next reboot or after you run partprobe(8) or kpartx(8)
    Syncing disks.
    [email protected]:/# reboot
  • Once you’re back from reboot we need to expand the filesystem to cover the new partition. Don’t forget to sudo -i to become root.
    [email protected]:/# df
    Filesystem     1K-blocks   Used Available Use% Mounted on
    rootfs           1811704 740184    977824  44% /
    /dev/root        1811704 740184    977824  44% /
    devtmpfs          253920      0    253920   0% /dev
    tmpfs              50816    216     50600   1% /run
    tmpfs               5120      0      5120   0% /run/lock
    tmpfs             101620      0    101620   0% /run/shm
    /dev/mmcblk0p1      1004    474       530  48% /boot/uboot
    [email protected]:/#

    [email protected]:/# resize2fs /dev/mmcblk0p2
    resize2fs 1.42.5 (29-Jul-2012)
    Filesystem at /dev/mmcblk0p2 is mounted on /; on-line resizing required
    old_desc_blocks = 1, new_desc_blocks = 1
    The filesystem on /dev/mmcblk0p2 is now 963328 blocks long.

    [email protected]:/# df
    Filesystem     1K-blocks   Used Available Use% Mounted on
    rootfs           3761680 741096   2851404  21% /
    /dev/root        3761680 741096   2851404  21% /
    devtmpfs          253920      0    253920   0% /dev
    tmpfs              50816    216     50600   1% /run
    tmpfs               5120      0      5120   0% /run/lock
    tmpfs             101620      0    101620   0% /run/shm
    /dev/mmcblk0p1      1004    474       530  48% /boot/uboot
    [email protected]:/#

1) CRTMP Server installation

CRTMP server is a streaming media server very similar to wowza. I use this to point ffmpeg at and to get playback on JWplayer. Grab the source code and follow the instructions for installing it on Ubuntu from http://wiki.rtmpd.com/quickbuild. You will need to create your build environment before you start building so do the command below to setup your environment and get the prerequisites installed:

  • Install needed packages
    [email protected]:/# apt-get install g++ subversion cmake make libssl-dev
  • Run these two additional commands
    [email protected]:/# apt-get install libcurl4-openssl-dev pkg-config
    [email protected]:/# pkg-config openssl --cflags --libs
  • Make sure that the last commands output was “-lssl -lcrypto”
  • Fetch the latest repo version of CRTMP
    cd /opt
    svn co --username anonymous --password "" https://svn.rtmpd.com/crtmpserver/trunk crtmpserver
    cd /crtmpserver/builders/cmake/cmake_find_modules
  • Edit the file Find_openssl.cmake and add the following path to the PATHS section of ssl, crypto and z sections above /usr/lib64 line:
    /usr/lib/arm-linux-gnueabihf
  • Edit the file Find_pcap.cmake and add the following path to the PATHS section of pcap sections above /usr/lib64 line:
    /usr/lib/arm-linux-gnueabihf
  • Edit the file Find_dl.cmake and add the following path to the PATHS section of dl sections above /usr/lib64 line:
    /usr/lib/arm-linux-gnueabihf
  • Edit the file Find_lua.cmake and add the following path to the PATHS section of lua sections above /usr/lib64 line:
    /usr/lib/arm-linux-gnueabihf
  • Might have to do this if locale is giving you grief (Note: I’ve picked en_CA since I live in Canada, you need to pick the right one for your country/region):
    [email protected]:/opt/crtmpserver/builders/cmake/cmake_find_modules# sudo locale-gen en_CA en_CA.UTF-8

    Generating locales...

    en_CA.ISO-8859-1... done

    en_CA.UTF-8... done

    Generation complete.

    [email protected]:/opt/crtmpserver/builders/cmake/cmake_find_modules# dpkg-reconfigure locales

    Generating locales...

    en_CA.ISO-8859-1... up-to-date

    en_CA.UTF-8... up-to-date

    en_US.UTF-8... done

    Generation complete.
  • Start building crtmp
    [email protected]:/opt/crtmpserver/builders/cmake# ./run

  • This process will take a while……go have a couple of coffee’s and/or snacks

Once this process is finished you’ll end up with the executable in /opt/crtmpserver/builders/cmake/crtmpserver, but that’s not how you run it. First you need a config file — you can edit crtmpserver.lua in /opt/crtmpserver/builders/cmake/crtmpserver or save a copy of the original and create a new one with the content from below (I’ve just cleaned up the original a tiny bit).

-- Start of the configuration. This is the only node in the config file.
-- The rest of them are sub-nodes
configuration=
{
	-- if true, the server will run as a daemon.
	-- NOTE: all console appenders will be ignored if this is a daemon
	daemon=false,
	-- the OS's path separator. Used in composing paths
	pathSeparator="/",

	-- this is the place where all the logging facilities are setted up
	-- you can add/remove any number of locations

	logAppenders=
	{
		{
			-- name of the appender. Not too important, but is mandatory
			name="console appender",
			-- type of the appender. We can have the following values:
			-- console, coloredConsole and file
			-- NOTE: console appenders will be ignored if we run the server
			-- as a daemon
			type="coloredConsole",
			-- the level of logging. 6 is the FINEST message, 0 is FATAL message.
			-- The appender will "catch" all the messages below or equal to this level
			-- bigger the level, more messages are recorded
			level=6
		},
		{
			name="file appender",
			type="file",
			level=6,
			-- the file where the log messages are going to land
			fileName="/tmp/crtmpserver",
			--newLineCharacters="\r\n",
			fileHistorySize=10,
			fileLength=1024*256,
			singleLine=true
		}
	},

	-- this node holds all the RTMP applications
	applications=
	{
		-- this is the root directory of all applications
		-- usually this is relative to the binary execuable
		rootDirectory="applications",

		--this is where the applications array starts
		{
			-- The name of the application. It is mandatory and must be unique
			name="appselector",
			-- Short description of the application. Optional
			description="Application for selecting the rest of the applications",

			-- The type of the application. Possible values are:
			-- dynamiclinklibrary - the application is a shared library
			protocol="dynamiclinklibrary",
			-- the complete path to the library. This is optional. If not provided,
			-- the server will try to load the library from here
			-- //lib.{so|dll|dylib}
			-- library="/some/path/to/some/shared/library.so"

			-- Tells the server to validate the clien's handshake before going further.
			-- It is optional, defaulted to true
			validateHandshake=false,
			-- this is the folder from where the current application gets it's content.
			-- It is optional. If not specified, it will be defaulted to:
			-- //mediaFolder
			-- mediaFolder="/some/directory/where/media/files/are/stored"
			-- the application will also be known by that names. It is optional
			--aliases=
			--{
			--	"simpleLive",
			--	"vod",
			--	"live",
			--},
			-- This flag designates the default application. The default application
			-- is responsable of analyzing the "connect" request and distribute
			-- the future connection to the correct application.
			default=true,
			acceptors =
			{
				{
					ip="0.0.0.0",
					port=1935,
					protocol="inboundRtmp"
				},
				{
					ip="0.0.0.0",
					port=8081,
					protocol="inboundRtmps",
					sslKey="server.key",
					sslCert="server.crt"
				},
				{
					ip="0.0.0.0",
					port=8080,
					protocol="inboundRtmpt"
                },
			}
		},
		{
			description="FLV Playback Sample",
			name="flvplayback",
			protocol="dynamiclinklibrary",
			aliases=
			{
				"simpleLive",
				"vod",
				"live",
				"WeeklyQuest",
				"SOSample",
				"oflaDemo",
			},
			acceptors =
			{
				{
					ip="0.0.0.0",
					port=6666,
					protocol="inboundLiveFlv",
					waitForMetadata=true,
				},
				{
					ip="0.0.0.0",
					port=9999,
					protocol="inboundTcpTs"
				},
				{
					ip="0.0.0.0",
					port=10000,
					protocol="inboundUdpTs"
				},
				--[[{
					ip="0.0.0.0",
					port=7654,
					protocol="inboundRawHttpStream",
					crossDomainFile="/tmp/crossdomain.xml"
				}, ]]--
				{
					ip="0.0.0.0",
					port=554,
					protocol="inboundRtsp"
				},
			},
			externalStreams =
			{
				--[[
				{
					uri="rtsp://fms20.mediadirect.ro/live2/realitatea/realitatea",
					localStreamName="rtsp_test",
					forceTcp=true
				},
				{
					uri="rtmp://edge01.fms.dutchview.nl/botr/bunny",
					localStreamName="rtmp_test",
					swfUrl="http://www.example.com/example.swf",
					pageUrl="http://www.example.com/",
					tcUrl="rtmp://edge01.fms.dutchview.nl/botr/bunny", --this one is usually required and should have the same value as the uri
					emulateUserAgent="MAC 10,1,82,76",
				}
				{
                        		uri="rtsp://animalhousenc.dvrdns.org:554/streaming/channels/0",
                        		localStreamName="PoolSide",
                        		forceTcp=true
                		},
               		 	{
                       			 uri="rtsp://animalhousenc.dvrdns.org:556/streaming/channels/0",
                       			 localStreamName="BoneYard",
                       			 forceTcp=true
                		},
                		{
                       			 uri="rtsp://animalhousenc.dvrdns.org:557/streaming/channels/0",
                       			 localStreamName="BigPool",
                       			 forceTcp=true
                		},
               		 	{
                       			 uri="rtsp://192.168.1.186:554/mpeg4/media.amp?videocodec=h264&streamprofile=high",
                       			 localStreamName="nerd",
                       			 forceTcp=true
                		},
               		 	{
                       			 uri="rtsp://192.168.1.190:554/0",
                       			 localStreamName="leopard",
                       			 forceTcp=true
                		}, ]]--
			},
			validateHandshake=false,
			--enableCheckBandwidth=true,
			--[[authentication=
			{
				rtmp={
					type="adobe",
					encoderAgents=
					{
						"FMLE/3.0 (compatible; FMSc/1.0)",
						"My user agent",
					},
					usersFile="users.lua"
				},
				rtsp={
					usersFile="users.lua"
				}
			}, --]]
			mediaStorage = {
			--[[	namedStorage1={
					--this storage contains all properties with their
					--default values. The only mandatory property is
					--mediaFolder
					description="Some storage",
					mediaFolder="/Volumes/Storage/media/",
					metaFolder="/tmp/metadata",
					enableStats=false,
					clientSideBuffer=15,
					keyframeSeek=false,
					seekGranularity=0.1,
				},
				namedStorage2={
					mediaFolder="/Volumes/Storage/media/mp4",
					metaFolder="/tmp/metadata",
					seekGranularity=0.2,
					enableStats=true,
				},
				namedStorage3={
					mediaFolder="/Volumes/Storage/media/flv",
					metaFolder="/tmp/metadata",
				},
				{
					--this one doesn't have a name
					mediaFolder="/Volumes/Storage/media/mp3",
				} --]]
			},
		},
		{
			name="samplefactory",
			description="asdsadasdsa",
			protocol="dynamiclinklibrary",
			aliases=
			{
				"httpOutboundTest"
			},
			acceptors =
			{
				{
					ip="0.0.0.0",
					port=8989,
					protocol="httpEchoProtocol"
				},
				{
					ip="0.0.0.0",
					port=8988,
					protocol="echoProtocol"
				}
			},
			validateHandshake=false,
			--default=true,
		},
		{
			name="vptests",
			description="Variant protocol tests",
			protocol="dynamiclinklibrary",
			aliases=
			{
				"vptests_alias1",
				"vptests_alias2",
				"vptests_alias3",
			},
			acceptors =
			{
				{
					ip="0.0.0.0",
					port=1111,
					protocol="inboundHttpXmlVariant"
				}
			},
			validateHandshake=false,
			--default=true,
		},
		{
			name="admin",
			description="Application for administering",
			protocol="dynamiclinklibrary",
			aliases=
			{
				"admin_alias1",
				"admin_alias2",
				"admin_alias3",
			},
			acceptors =
			{
				{
					ip="0.0.0.0",
					port=1112,
					protocol="inboundJsonCli",
					useLengthPadding=true
				},
			},
			validateHandshake=false,
			--default=true,
		},
		{
			name="proxypublish",
			description="Application for forwarding streams to another RTMP server",
			protocol="dynamiclinklibrary",
			acceptors =
			{
				{
					ip="0.0.0.0",
					port=6665,
					protocol="inboundLiveFlv"
				},
			},
			abortOnConnectError=true,
			targetServers =
			{
				--[[{
					targetUri="rtmp://x.xxxxxxx.fme.ustream.tv/ustreamVideo/xxxxxxx",
					targetStreamName="xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx",
					localStreamName="stream1",
					emulateUserAgent="FMLE/3.0 (compatible; FMSc/1.0 http://www.rtmpd.com)"
				}]]--,
				--[[{
					targetUri="rtmp://gigi:[email protected]/vod",
					targetStreamType="live", -- (live, record or append)
					emulateUserAgent="My user agent",
					localStreamName="stream1",
					keepAlive=true
				},]]--
			},
			externalStreams =
			{
				--[[{
					uri="rtsp://fms20.mediadirect.ro/live2/realitatea/realitatea",
					localStreamName="stream1",
					forceTcp=true,
					keepAlive=true
				},]]--
			},
			validateHandshake=false,
			--default=true,
		},
		{
			name="stresstest",
			description="Application for stressing a streaming server",
			protocol="dynamiclinklibrary",
			targetServer="localhost",
			targetApp="vod",
			active=false,
			--[[streams =
			{
				"lg00","lg01","lg02","lg03","lg04","lg05","lg06","lg07","lg08",
				"lg09","lg10","lg11","lg12","lg13","lg14","lg15","lg16","lg17",
				"lg18","lg19","lg20","lg21","lg22","lg23","lg24","lg25","lg26",
				"lg27","lg28","lg29","lg30","lg31","lg32","lg33","lg34","lg35",
				"lg36","lg37","lg38","lg39","lg40","lg41","lg42","lg43","lg44",
				"lg45","lg46","lg47","lg48","lg49"
			},]]--
			streams =
			{
				"mp4:lg.mp4"
			},
			numberOfConnections=10,
			randomAccessStreams=false
		},
		--[[{
			name="vmapp",
			description="An application demonstrating the use of virtual machines",
			protocol="dynamiclinklibrary",
			vmType="lua",
			script="flvplayback.lua",
			aliases=
			{
				"flvplayback1",
				"vod1"
			},
			acceptors=
			{
				{
					ip="0.0.0.0",
					port=6544,
					protocol="inboundTcpTs"
				}
			}
		},]]--
		--#INSERTION_MARKER# DO NOT REMOVE THIS. USED BY appscaffold SCRIPT.
	}
}

Once you have this saved (or modified yours to look like this you can go ahead and try to start the server with the following command (NOTE: you need to be in the cmake directory (rather than crtmpserver) and reference the files with partial paths……not sure why…..something to do with cmake base directory).

cd /opt/crtmpserver/builders/cmake/
./crtmpserver/crtmpserver ./crtmpserver/crtmpserver.lua

You should get output similar this this

/crtmpserver/src/crtmpserver.cpp:216 C++ RTMP Media Server (www.rtmpd.com) version 1.1_rc1 build 808 - Gladiator - (built on 2013-09-28T21:19:24.000)
/crtmpserver/src/crtmpserver.cpp:219 OS files descriptors count limits: 4096/4096
/crtmpserver/src/crtmpserver.cpp:221 Initialize I/O handlers manager: epoll without timerfd_XXXX support
/crtmpserver/src/crtmpserver.cpp:224 Configure modules
/crtmpserver/src/crtmpserver.cpp:230 Plug in the default protocol factory
/crtmpserver/src/crtmpserver.cpp:237 Configure factories
/thelib/src/configuration/module.cpp:97 Loaded factory from application samplefactory
/crtmpserver/src/crtmpserver.cpp:243 Configure acceptors
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 0->1 IOHT_ACCEPTOR
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 1->2 IOHT_ACCEPTOR
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 2->3 IOHT_ACCEPTOR
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 3->4 IOHT_ACCEPTOR
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 4->5 IOHT_ACCEPTOR
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 5->6 IOHT_ACCEPTOR
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 6->7 IOHT_UDP_CARRIER
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 7->8 IOHT_ACCEPTOR
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 8->9 IOHT_ACCEPTOR
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 9->10 IOHT_ACCEPTOR
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 10->11 IOHT_ACCEPTOR
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 11->12 IOHT_ACCEPTOR
/crtmpserver/src/crtmpserver.cpp:249 Configure instances
/crtmpserver/src/crtmpserver.cpp:255 Start I/O handlers manager: epoll without timerfd_XXXX support
/crtmpserver/src/crtmpserver.cpp:258 Configure applications
/thelib/src/configuration/module.cpp:177 Application admin instantiated
/thelib/src/configuration/module.cpp:177 Application appselector instantiated
/thelib/src/configuration/module.cpp:177 Application flvplayback instantiated
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 12->13 IOHT_TIMER
/thelib/src/configuration/module.cpp:177 Application proxypublish instantiated
/thelib/src/netio/epoll/iohandlermanager.cpp:120 Handlers count changed: 13->14 IOHT_TIMER
/thelib/src/configuration/module.cpp:177 Application samplefactory instantiated
/thelib/src/configuration/module.cpp:177 Application stresstest instantiated
/thelib/src/configuration/module.cpp:177 Application vptests instantiated
/crtmpserver/src/crtmpserver.cpp:264 Install the quit signal
/crtmpserver/src/crtmpserver.cpp:275
+-----------------------------------------------------------------------------+
|                                                                     Services|
+---+---------------+-----+-------------------------+-------------------------+
| c |      ip       | port|   protocol stack name   |     application name    |
+---+---------------+-----+-------------------------+-------------------------+
|tcp|        0.0.0.0| 1112|           inboundJsonCli|                    admin|
+---+---------------+-----+-------------------------+-------------------------+
|tcp|        0.0.0.0| 1935|              inboundRtmp|              appselector|
+---+---------------+-----+-------------------------+-------------------------+
|tcp|        0.0.0.0| 8081|             inboundRtmps|              appselector|
+---+---------------+-----+-------------------------+-------------------------+
|tcp|        0.0.0.0| 8080|             inboundRtmpt|              appselector|
+---+---------------+-----+-------------------------+-------------------------+
|tcp|        0.0.0.0| 6666|           inboundLiveFlv|              flvplayback|
+---+---------------+-----+-------------------------+-------------------------+
|tcp|        0.0.0.0| 9999|             inboundTcpTs|              flvplayback|
+---+---------------+-----+-------------------------+-------------------------+
|udp|        0.0.0.0|10000|             inboundUdpTs|              flvplayback|
+---+---------------+-----+-------------------------+-------------------------+
|tcp|        0.0.0.0|  554|              inboundRtsp|              flvplayback|
+---+---------------+-----+-------------------------+-------------------------+
|tcp|        0.0.0.0| 6665|           inboundLiveFlv|             proxypublish|
+---+---------------+-----+-------------------------+-------------------------+
|tcp|        0.0.0.0| 8989|         httpEchoProtocol|            samplefactory|
+---+---------------+-----+-------------------------+-------------------------+
|tcp|        0.0.0.0| 8988|             echoProtocol|            samplefactory|
+---+---------------+-----+-------------------------+-------------------------+
|tcp|        0.0.0.0| 1111|    inboundHttpXmlVariant|                  vptests|
+---+---------------+-----+-------------------------+-------------------------+
/crtmpserver/src/crtmpserver.cpp:276 GO! GO! GO! (2368)

So far so good……the server is up and running now. You can stop it using Ctrl-C. Lets continue…….

2) C920 install and config (v4l2), ffmpeg installation, boneCV installation from Derek Molloy’s site

Logitec C920 is a really nice camera. Bit on the expensive side, but incredibly capable as we’ll see. I came across a post from Derek Molloy where he talks about UDP streaming h.264 streams off the C920 using a beagle board. That’s when I discovered the magic of this little camera. You see, the camera can provide image data via usb just like any other camera, but it also has the built in capability of producing a 3.5 Mb/s CBR video stream encoded in h.264 in either 640×480, 1280×720 or 1920×1080. I literally jumped out of my seat when I read this and picked one up from the local Best Buy (about $100). So now to get this signal in we need some of the tools that come with v4l (video4linux) utility package. Here is how you go about it:

  • First we need to install v4l-utils, ffmpeg and git (need git to grab the code in next step)
    apt-get install v4l-utils ffmpeg git
  • Then we need to pull down some code Derek has modified (and or written) from his git repo
    cd /opt
    git clone git://github.com/derekmolloy/boneCV

  • Next we need to get into the boneCV directory and recompile Derek’s capture.c program
    cd /opt/boneCV
    gcc -o capture capture.c
  • Now that we have the fresh capture program maybe we should stop and let me explain. capture.c is a V4L2 video capture example, modified by Derek Molloy for the Logitech C920 camera. He’s added the -F mode for H264 capture and associated help detail, plus an option to allow capture to capture infinite number of frames. Before we continue to the next step it’s worth trying to visualize the chain we’re trying to create. Capture (capture.c) will be called to put the camera in -F mode (1080p h.264 pre-encoded 3.5Mb/s CBR stream over USB) and to continuously pass the frames to a pipe which will feed avconv (a program that comes with ffmpeg) that will not touch the video encoding of the file but will transmit it to a RTSP destination (our crtmp streaming server). Once the stream is runnning we will use JWplayer to view the RTMP stream. The reason I decided to use JWplayer is that various incarnations of VLC say they support RTMP, but their implementation is really bad. For the longest time while using VLC to view the stream (I think it was version 2.1.x and 2.2.x nightly builds) I had freezes and breakups in the stream and I thought the poor Pi was not doing it’s job. NO, it was the player, the Pi (and Beagle Board Black) worked wonderfully. So now we need to modify the streamVideoRTSP file Derek has to look like the following (might want to save the original as .bak or something).
    #!/bin/bash
    echo "Video Streaming for the Beaglebone - derekmolloy.ie"
    echo "Piping the output of capture to avconv"
    #1080P mode
    v4l2-ctl --set-fmt-video=width=1920,height=1080,pixelformat=1
    #720P mode
    #v4l2-ctl --set-fmt-video=width=1280,height=720,pixelformat=1

    # Pipe the output of capture into avconv/ffmpeg
    # capture "-F"   My H264 passthrough mode
    #         "-o"   Output the video (to be passed to avconv via pipe)
    #         "-c0"  Capture 0 frames, which means infinite frames in my program
    # avconv "-i -"  Take the input from the pipe
    #        "-vcodec copy" Do not transcode the video

    #1080P mode
    ./capture -F -o -c0|avconv -re -i - -f alsa -ac 2 -i hw:1,0 -strict experimental -threads 0 -acodec aac -ab 64k -ac 2 -vcodec copy -f  rtsp -metadata title=teststream rtsp://127.0.01:554/live
    #720P mode
    #./capture -f -o -c0|avconv -re -i - -f alsa -ac 2 -i hw:1,0 -strict experimental -threads 0 -acodec aac -ab 64k -ac 2 -vcodec copy -f  rtsp -metadata title=teststream rtsp://127.0.01:554/live


3) Configuring ddclient for dynamic DNS (optional)

This is totally optional and has no effect on the final product (makes life a bit simpler). I’m just going to provide the bare minimum explanation and my config. This process is very dependant on your DNS provider (if you have one), my example config is for my provider easydns.com. Your mileage will vary :-).

  • First we need to get ddclient program installed (this is one of dynamic dns tools available in linux)
    apt-get install ddclient
  • Then we need to edit the config file located in /etc called ddclient.conf. Here is mine which is specific for easydns.com. YOU WILL HAVE TO MODIFY THIS TO SUITE YOUR DNS PROVIDER.

    # Configuration file for ddclient generated by debconf
    #
    # /etc/ddclient.conf
    # updates internet ip on wired
    protocol=easydns,
    # Use this is you want to register the interface ip address (ie: You're not behind a NAT or you don't care)
    use=if, if=eth0,
    # Use this is you want to register your external ip address (ie: You're behind a NAT and want to register your outside IP address not the internal 192.168.x.x one)
    #use=web, web=checkip.dyndns.com/, web-skip='IP Address'
    server=members.easydns.com,
    login=easydnsuserid,
    password='easydnspassword',
    hostname.domain.com

  • If you’ve enabled two factor authentication on easyDNS (or maybe even if you have not) there is a token that you’ll need to get called “Dynamic Authentication Token”. You can grab yours under the dynamic records page by enabling “Dynamic Authentication Token” and vieing your code. I will use XXXXXXXXXXXXXXXX as my code in the following example (NOTE: server and password clauses need to be changed):

    # Configuration file for ddclient generated by debconf
    #
    # /etc/ddclient.conf
    # updates internet ip on wired
    protocol=easydns,
    # Use this is you want to register the interface ip address (ie: You're not behind a NAT or you don't care)
    use=if, if=eth0,
    # Use this is you want to register your external ip address (ie: You're behind a NAT and want to register your outside IP address not the internal 192.168.x.x one)
    #use=web, web=checkip.dyndns.com/, web-skip='IP Address'
    server=api.cp.easydns.com,
    login=easydnsuserid,
    password='XXXXXXXXXXXXXXXX',
    hostname.domain.com

  • Once the config is there we can restart the ddclient service
    service ddclient restart
  • If you want to check/test/debug your ddclient config, first stop the daemon that’s running in the backgroud, start it from command line in forground like below
    service ddclient stop
    ddclient -daemon=0 -debug -verbose -noquiet

4) Putting it all together and creating a webpage with embedded JWplayer to view the stream

So now you need to grab JWplayer (the free version) install it (copy the jwplayer folder) into a folder on your webserver (I copied mine into a folder of my blog server). The main file here is the HTML file that has the specifications for the stream in it. You need to create this to suite your need (ie: if you have dynamic DNS use the DNS name or if you don’t use the IP address of the Pi/BeagleBoard. Your mileage will vary :-).

Screen Shot 2013-11-09 at 4.42.17 PM

The above code is an example you will need to sustitute your own data to get it to work. We need two ssh windows off the Pi (one to run the crtmpserver and the other to start capturing and feeding it via streamVideoRTSP script. So go ahead start crtmp (see above….we did this as a test in step 1) and in the other window start streamVideoRTSP script. Those two windows should look like this:

Screen Shot 2013-11-09 at 4.59.39 PM

That’s pretty much it. If you now load the html file for jwplayer and press play (assuming you’ve done everything correctly) the stream should start playing in about 4-5 seconds. The encoding delay in the entire chain is about 2-3 seconds, the quality (considering it’s a webcam feeding a $35 computer) is really good and given proper power the Pi can steam this 1080p/30 stream without a issue. Just for the fun of it I also (at the same time) tried to feed the crtmp server (on the pi) a seperate quarter rez HD stream (640×360) encoded by ffmpeg on my desktop and yep, no problems (although the Pi is on medium overclocking settings). These RTMP streams can also be very easily scaled by passing them to larger crtmp installations and/or ustream/wowza for rebroadcast. Below you’ll find a bunch of ffmpeg command line entries I used for this second stream and also a quick (optional) write up on how I got the wireless dongle from Trendnet to work and configured from CLI.

./ffmpeg -re -i /Volumes/Qmultimedia/1217209\(73\).avi -vcodec libx264  -b 500000 -s 640x360 -strict experimental -g 25 -me_method zero -acodec aac -ab 96000 -ar 48000 -ac 2 -vbsf h264_mp4toannexb -f mpegts -metadata title=xxx udp://192.168.1.69:10000?pkt_size=1316
./ffmpeg -re -i /Volumes/Qmultimedia/1217209\(73\).avi -vcodec libx264  -b 500000 -s 640x360 -strict experimental -g 25 -me_method zero -acodec aac -ab 96000 -ar 48000 -ac 2 -f flv rtmp://192.168.1.69:1935/live/xxx
./ffmpeg -re -i /Volumes/Qmultimedia/1217209\(73\).avi -vcodec libx264  -b 500000 -s 640x360 -strict experimental -g 25 -me_method zero -acodec aac -ab 96000 -ar 48000 -ac 2 -f rtsp -metadata title=xxx rtsp://192.168.1.69:554/live

For wireless I’m using a TrendNet TEW-645UB which is directly supported under linux. Initially I used wpa_cli to get things configured and once the system was configured I massaged the files a bit. Here is a log of the whole thing:

[email protected]:~# lsusb
Bus 001 Device 002: ID 0424:9512 Standard Microsystems Corp.
Bus 001 Device 001: ID 1d6b:0002 Linux Foundation 2.0 root hub
Bus 001 Device 003: ID 0424:ec00 Standard Microsystems Corp.
Bus 001 Device 004: ID 157e:3013 TRENDnet
Bus 001 Device 006: ID 046d:082d Logitech, Inc.
[email protected]:~# wpa_cli
wpa_cli v1.0
Copyright (c) 2004-2012, Jouni Malinen <[email protected]> and contributors

This program is free software. You can distribute it and/or modify it
under the terms of the GNU General Public License version 2.

Alternatively, this software may be distributed under the terms of the
BSD license. See README and COPYING for more details.

Selected interface 'wlan0'

Interactive mode

> scan
OK
CTRL-EVENT-SCAN-RESULTS
> scan_results
bssid / frequency / signal level / flags / ssid
7c:d1:c3:zz:yy:xx	2411	-50	[WPA2-PSK-CCMP][ESS]	Nerdlogger
7c:d1:c3:zz:yy:xx	2412	-51	[WPA2-PSK-CCMP][ESS]	MaNiAc 2Ghz
8c:7c:b5:zz:yy:xx	2437	-64	[WPA-PSK-CCMP][ESS]	PS3-3313551
> add_network
0
> set_network 0 ssid "Nerdlogger"
OK
> set_network 0 psk "supersecretpassword"
OK
> enable_network 0
OK
> add_network
1
> set_network 1 ssid "MaNiAc 2Ghz"
OK
> set_network 1 psk "supersecretpassword"
OK
> enable_network 1
OK
> save_config
OK
> quit
>
[email protected]:~# iwconfig
wlan0     IEEE 802.11bgn  ESSID:"MaNiAc 2Ghz"
          Mode:Managed  Frequency:2.412 GHz  Access Point: 7C:D1:C3:CA:0F:7A
          Bit Rate=43.3 Mb/s   Tx-Power=20 dBm
          Retry  long limit:7   RTS thr:off   Fragment thr:off
          Encryption key:off
          Power Management:on
          Link Quality=59/70  Signal level=-51 dBm
          Rx invalid nwid:0  Rx invalid crypt:0  Rx invalid frag:0
          Tx excessive retries:0  Invalid misc:1   Missed beacon:0

lo        no wireless extensions.

eth0      no wireless extensions.

[email protected]:~# ifconfig
eth0      Link encap:Ethernet  HWaddr b8:27:eb:37:a6:b3
          inet addr:192.168.1.189  Bcast:192.168.1.255  Mask:255.255.255.0
          UP BROADCAST RUNNING MULTICAST  MTU:1500  Metric:1
          RX packets:10397 errors:0 dropped:1 overruns:0 frame:0
          TX packets:5361 errors:0 dropped:0 overruns:0 carrier:0
          collisions:0 txqueuelen:1000
          RX bytes:726543 (709.5 KiB)  TX bytes:918179 (896.6 KiB)

lo        Link encap:Local Loopback
          inet addr:127.0.0.1  Mask:255.0.0.0
          UP LOOPBACK RUNNING  MTU:16436  Metric:1
          RX packets:0 errors:0 dropped:0 overruns:0 frame:0
          TX packets:0 errors:0 dropped:0 overruns:0 carrier:0
          collisions:0 txqueuelen:0
          RX bytes:0 (0.0 B)  TX bytes:0 (0.0 B)

wlan0     Link encap:Ethernet  HWaddr 00:14:d1:cc:16:d2
          inet addr:192.168.1.69  Bcast:192.168.1.255  Mask:255.255.255.0
          UP BROADCAST RUNNING MULTICAST  MTU:1500  Metric:1
          RX packets:1389 errors:0 dropped:41 overruns:0 frame:0
          TX packets:36 errors:0 dropped:0 overruns:0 carrier:0
          collisions:0 txqueuelen:1000
          RX bytes:466517 (455.5 KiB)  TX bytes:4773 (4.6 KiB)

[email protected]:~# cat /etc/network/interfaces
auto lo

iface lo inet loopback
auto eth0
iface eth0 inet dhcp

auto wlan0
allow-hotplug wlan0
iface wlan0 inet manual
	wpa-driver wext
	wpa-roam /etc/wpa_supplicant/wpa_supplicant.conf

iface default inet dhcp

iface work inet dhcp

iface home inet static
	address 192.168.1.69
	netmask 255.255.255.0
	network 192.168.1.0
	broadcast 192.168.1.255
	gateway 192.168.1.1
	dns-nameservers 192.168.1.1

[email protected]:~# cat /etc/wpa_supplicant/wpa_supplicant.conf
ctrl_interface=DIR=/var/run/wpa_supplicant GROUP=netdev
update_config=1

network={
	ssid="Nerdlogger"
	psk="supersecretpassword"
	id_str="work"
}

network={
	ssid="MaNiAc 2Ghz"
	psk="supersecretpassword"
	id_str="home"
}

[email protected]:~#

After battling this for about a week I think I’ve got it figured out. You can install all the required packages and get everything to talk to your license server from command line. BTW, before I start, you need to have a functional license server otherwise you can stop reading now. I’m gonna use licserver.com as the domain name of mine, so substitute your DNS name where necessary. Before we start you need to figure out your product codes from the table at the following address:

http://usa.autodesk.com/adsk/servlet/ps/dl/item?siteID=123112&id=21481916&linkID=12305695

My products are Maya (657F1), Mudbox (498F1) and my Suite number for ECSU is 793F1. You’ll need these later. Also my base directory (current directory) in these commands is “MacOSX”, there are separate folders for the individual ECSU apps under this folder. First we install Maya:

installer -verbose -pkg ./Maya/Install\ Maya\ 2014.app/Contents/Resources/Maya/Maya2014.mpkg -target /

Then we create a file named Maya2014.lic in folder /private/var/flexlm and put the following text inside it:

SERVER licserver.com 0
USE_SERVER

Make sure this file has at least read permission for group and others (mine is 744). Then we create another file named License.env in folder /Applications/Autodesk/maya2014/ and put the following text inside it:

MAYA_LICENSE=unlimited
MAYA_LICENSE_METHOD=network

Install the standalone adlmgr package (you’ll get errors later if you don’t do this):

installer -pkg ./MacOSX/Maya/Install\ Maya\ 2014.app/Contents/Resources/Maya/Additional\ Items/AdLM_standalone.mpkg -target /

Now comes the fun part of enrolling the serial number into the license manager. Remember the Product code and the Suite code I had you look up earlier, we need them now. In the following command line -i inserts, “N” is for network license type, First Code is the Product code (Maya) and the second code is the Suite code (ECSU in my case). The following command should get the license added (use the proper serial# starting with 379):

adlmreg -i N 657F1 793F1 2014.0.0.F 379-XXXXXXXX /Library/Application\ Support/Autodesk/Adlm/PIT/2014/MayaConfig.pit

If you screw up you can remove the license via this command:

adlmreg -u N 657F1

Next step is optional. When Maya starts it displays a bunch of intro screens. Since my deployment is run by a KACE appliance I need to be able to Pre-disable these popup screens. The following command will let you do that:

/usr/bin/defaults write /Library/Preferences/com.autodesk.MC3Framework MC3Enabled -int 0

Next we need to install all the Optional installs Maya comes with. Some of it is probably already installed by the Maya installer, but I installed them again for good measure. No harm done. Use the following 11 installer commands to install them:

installer -verboseR -pkg ./Maya/Install\ Maya\ 2014.app/Contents/Resources/Maya/Additional\ Items/ADC_docs8.0.pkg -target /
installer -verboseR -pkg ./Maya/Install\ Maya\ 2014.app/Contents/Resources/Maya/Additional\ Items/AutodeskBackburner2014.mpkg -target /
installer -verboseR -pkg ./Maya/Install\ Maya\ 2014.app/Contents/Resources/Maya/Additional\ Items/AutodeskDirectConnect8.0.pkg/ -target /
installer -verboseR -pkg ./Maya/Install\ Maya\ 2014.app/Contents/Resources/Maya/Additional\ Items/Composite2014.pkg -target /
installer -verboseR -pkg ./Maya/Install\ Maya\ 2014.app/Contents/Resources/Maya/Additional\ Items/MatchMover2014.pkg -target /
installer -verboseR -pkg ./Maya/Install\ Maya\ 2014.app/Contents/Resources/Maya/Additional\ Items/Maya_quicktime_components.pkg -target /
installer -verboseR -pkg ./Maya/Install\ Maya\ 2014.app/Contents/Resources/Maya/Additional\ Items/autodesk.backburner.monitor-2014.0_439_i386.pkg -target /
installer -verboseR -pkg ./Maya/Install\ Maya\ 2014.app/Contents/Resources/Maya/Additional\ Items/autodesk.dlcommon.libraries_2014.2-2043.i386.pkg -target /
installer -verboseR -pkg ./Maya/Install\ Maya\ 2014.app/Contents/Resources/Maya/Additional\ Items/autodesk.webentry-1.0-603.i386.pkg -target /
installer -verboseR -pkg ./Maya/Install\ Maya\ 2014.app/Contents/Resources/Maya/Additional\ Items/backburner-2014.0_1635_i386.pkg -target /
installer -verboseR -pkg ./Maya/Install\ Maya\ 2014.app/Contents/Resources/Maya/Additional\ Items/mentalrayForMaya2014.0.pkg -target /

Now check to make sure Maya is working and all the other extra little apps we installed are functional. They should be. If not stop and review. Assuming it’s all working, lets move on and install Mudbox and the last few optional installs. First we need to install Mudbox:

installer -verboseR -pkg ./Mudbox/Install\ Mudbox\ 2014.app/Contents/Resources/Mudbox/Mudbox2014.mpkg/ -target /

Then we need to create the License.env file in /Applications/Autodesk/Mudbox2014/ folder with the following content:

MUDBOX_LICENSE=unlimited
MUDBOX_LICENSE_METHOD=network

Now comes the fun part of enrolling the serial number into the license manager. Remember the Product code and the Suite code I had you look up earlier, we need them now. In the following command line -i inserts, “N” is for network license type, First Code is the Product code (Mudbox) and the second code is the Suite code (ECSU in my case). The following command should get the license added (use the proper serial# starting with 379):

adlmreg -i N 498F1 793F1 2014.0.0.F 379-XXXXXXXX /Library/Application\ Support/Autodesk/Adlm/PIT/2014/MudboxConfig.pit

If you screw up you can remove the license via this command:

adlmreg -u N 498F1

Only two more install command left to go. These are optional packages that are part of ECSU. Use the following two installer commands to get them installed:

installer -verboseR -pkg ./mentalraySatellite/Install\ mentalraysatellite\ 3.11.1.app/Contents/Resources/mrsat/mrsat3.11.1.mpkg -target /
installer -verboseR -pkg ./SuiteExclusives/Install\ Suite\ Exclusives\ 2014.app/Contents/Resources/Turtle/MayaTurtlePlugIn2014.0.pkg/ -target /

Now you should be able to run Mudbox and pretty much all the other apps that are in Autodesk folder under Applications. Hopefully it all worked out for you. I will try to get a KACE workflow done for this in the next few days. If you’re a KACE user and end up making the workflow before I do, please share :-).

Copying large number of files between two Unix/Linux/OSX Servers

datePosted on 14:38, August 15th, 2012 by Many Ayromlou

Here are some quick tip(s) for copying a ton of files between unixy machines really fast. You’re probably thinking “why not use rsync?”…..well rsync can be miserably slow if your source or destination cpu is underpowered. You can always do a rsync after these commands to make 100% certain that everything checks out, but try using one of these methods for the initial copy:

  • One way of doing it is
    tar -c /path/to/dir | ssh [email protected]_server 'tar -xpvf - -C /absolute/path/to/remotedir'

    You’ll be prompted for the remote servers password or you can use the private key of the remote server using the -i switch in the ssh command. This has the side benefit of preserving permissions. An alternate version of this command can also be used to locally move folder structures across mount points while preserving permissions:

    tar -cf - -C srcdir . | tar -xpf - -C destdir

    or

    cd srcdir ; tar -cf - . | (cd destdir ; tar -xpf -)
  • Another way of doing it with netcat (nc) is
    srv1$ tar -cfv - * | nc -w1 remote.server.net 4321

    followed by

    srv2$ nc -l -p 4321 |tar -xpfv -

    Note that you type the first command on the source machine and the second command on the destination machine.

  • Yet another way of doing it with socat utility is
    host1$ tar -cvf - * | socat stdin tcp4:host2:portnum

    followed by

    host2$ socat tcp4-listen:portnum stdout | tar -xvpf -

    Note that you type the first command on the source machine and the second command on the destination machine.

Once your favourite process (above) is done you can do a quick rsync to tie up any loose ends.

rsync -avW -e ssh /path/to/dir/ remote_server:/path/to/remotedir

Rsync will now fly through the filesystem as 99.9% of the time, 99.9% of the files on the destination are good. And as always make sure you understand the commands before you use them…..and keep backups just in case :-).

Flush DNS cache in Lion and Mountain Lion

datePosted on 21:11, August 8th, 2012 by Many Ayromlou

Flush DNS cache in Lion and Mountain Lion:

To flush the DNS cache in Mac OS X 10.5 and 10.6, run this command in Terminal:

sudo dscacheutil -flushcache

To do the same in 10.7 and 10.8, run this command:

sudo killall -HUP mDNSResponder

(Via MacOSXHints.com)

CLI commands that let you access meta data of all files in OSX

datePosted on 14:29, July 31st, 2012 by Many Ayromlou

Two small commands with huge possibilities:

  1. mdls
    usage: mdls [-name attr] [-raw [-nullMarker markerString]] [-plist file] path
    list the values of one or all the attributes of the specified file
    -raw: don't print attribute names before values
    -nullMarker: substitute this string for null attributes in raw mode
    -plist: output attributes in XML format to file. Use - to write to stdout
    option -plist is incompatible with options -raw, -nullMarker, and -name
    example: mdls ~/Pictures/Birthday.jpg
    example: mdls -name Keyword ~/Pictures/Birthday.jpg
  2. mdfind
    Usage: mdfind [-live] [-count] [-onlyin directory] [-name fileName | -s smartFolderName | query]
    list the files matching the query
    query can be an expression or a sequence of words

    	-live             Query should stay active
    	-count            Query only reports matching items count
    	-onlyin <dir>     Search only within given directory
    	-name <name>      Search on file name only
    	-s <name>         Show contents of smart folder <name>
    	-0                Use NUL (``\0'') as a path separator, for use with xargs -0.

    example:  mdfind image
    example:  mdfind -onlyin ~ image
    example:  mdfind -name stdlib.h
    example:  mdfind "kMDItemAuthor == '*MyFavoriteAuthor*'"
    example:  mdfind -live MyFavoriteAuthor

As pointed out to me in the comments the original Author — Mathias Bynens — is constantly updating this document. You can find the latest up to date version at http://mths.be/osx

# ~/.osx — http://mths.be/osx

###############################################################################
# General UI/UX #
###############################################################################

# Set computer name (as done via System Preferences → Sharing)
scutil --set ComputerName "MathBook Pro"
scutil --set HostName "MathBook Pro"
scutil --set LocalHostName "MathBook-Pro"

# Menu bar: disable transparency
defaults write NSGlobalDomain AppleEnableMenuBarTransparency -bool false

# Menu bar: show remaining battery time (on pre-10.8); hide percentage
defaults write com.apple.menuextra.battery ShowPercent -string "NO"
defaults write com.apple.menuextra.battery ShowTime -string "YES"

# Menu bar: hide the useless Time Machine and Volume icons
defaults write com.apple.systemuiserver menuExtras -array "/System/Library/CoreServices/Menu Extras/Bluetooth.menu" "/System/Library/CoreServices/Menu Extras/AirPort.menu" "/System/Library/CoreServices/Menu Extras/Battery.menu" "/System/Library/CoreServices/Menu Extras/Clock.menu"

# Always show scrollbars
defaults write NSGlobalDomain AppleShowScrollBars -string "Always"

# Disable smooth scrolling
# (Uncomment if you’re on an older Mac that messes up the animation)
#defaults write NSGlobalDomain NSScrollAnimationEnabled -bool false

# Disable opening and closing window animations
defaults write NSGlobalDomain NSAutomaticWindowAnimationsEnabled -bool false

# Increase window resize speed for Cocoa applications
defaults write NSGlobalDomain NSWindowResizeTime -float 0.001

# Expand save panel by default
defaults write NSGlobalDomain NSNavPanelExpandedStateForSaveMode -bool true

# Expand print panel by default
defaults write NSGlobalDomain PMPrintingExpandedStateForPrint -bool true

# Disable the “Are you sure you want to open this application?” dialog
defaults write com.apple.LaunchServices LSQuarantine -bool false

# Display ASCII control characters using caret notation in standard text views
# Try e.g. `cd /tmp; unidecode "\x{0000}" > cc.txt; open -e cc.txt`
defaults write NSGlobalDomain NSTextShowsControlCharacters -bool true

# Disable Resume system-wide
defaults write NSGlobalDomain NSQuitAlwaysKeepsWindows -bool false

# Disable automatic termination of inactive apps
defaults write NSGlobalDomain NSDisableAutomaticTermination -bool true

# Fix for the ancient UTF-8 bug in QuickLook (http://mths.be/bbo)
# Commented out, as this is known to cause problems when saving files in Adobe Illustrator CS5 :(
#echo "0x08000100:0" > ~/.CFUserTextEncoding

###############################################################################
# Trackpad, mouse, keyboard, Bluetooth accessories, and input #
###############################################################################

# Trackpad: enable tap to click for this user and for the login screen
defaults write com.apple.driver.AppleBluetoothMultitouch.trackpad Clicking -bool true
defaults -currentHost write NSGlobalDomain com.apple.mouse.tapBehavior -int 1
defaults write NSGlobalDomain com.apple.mouse.tapBehavior -int 1

# Trackpad: map bottom right corner to right-click
defaults write com.apple.driver.AppleBluetoothMultitouch.trackpad TrackpadCornerSecondaryClick -int 2
defaults write com.apple.driver.AppleBluetoothMultitouch.trackpad TrackpadRightClick -bool true
defaults -currentHost write NSGlobalDomain com.apple.trackpad.trackpadCornerClickBehavior -int 1
defaults -currentHost write NSGlobalDomain com.apple.trackpad.enableSecondaryClick -bool true

# Trackpad: swipe between pages with three fingers
defaults write NSGlobalDomain AppleEnableSwipeNavigateWithScrolls -bool true
defaults -currentHost write NSGlobalDomain com.apple.trackpad.threeFingerHorizSwipeGesture -int 1
defaults write com.apple.driver.AppleBluetoothMultitouch.trackpad TrackpadThreeFingerHorizSwipeGesture -int 1

# Disable “natural” (Lion-style) scrolling
defaults write NSGlobalDomain com.apple.swipescrolldirection -bool false

# Increase sound quality for Bluetooth headphones/headsets
defaults write com.apple.BluetoothAudioAgent "Apple Bitpool Min (editable)" -int 40

# Enable full keyboard access for all controls
# (e.g. enable Tab in modal dialogs)
defaults write NSGlobalDomain AppleKeyboardUIMode -int 3

# Disable press-and-hold for keys in favor of key repeat
defaults write NSGlobalDomain ApplePressAndHoldEnabled -bool false

# Set a blazingly fast keyboard repeat rate
defaults write NSGlobalDomain KeyRepeat -int 0

# Set language and text formats
# Note: if you’re in the US, replace `EUR` with `USD`, `Centimeters` with
# `Inches`, and `true` with `false`.
defaults write NSGlobalDomain AppleLanguages -array "en" "nl"
defaults write NSGlobalDomain AppleLocale -string "[email protected]=EUR"
defaults write NSGlobalDomain AppleMeasurementUnits -string "Centimeters"
defaults write NSGlobalDomain AppleMetricUnits -bool true

# Disable auto-correct
defaults write NSGlobalDomain NSAutomaticSpellingCorrectionEnabled -bool false

###############################################################################
# Screen #
###############################################################################

# Require password immediately after sleep or screen saver begins
defaults write com.apple.screensaver askForPassword -int 1
defaults write com.apple.screensaver askForPasswordDelay -int 0

# Save screenshots to the desktop
defaults write com.apple.screencapture location -string "$HOME/Desktop"

# Save screenshots in PNG format (other options: BMP, GIF, JPG, PDF, TIFF)
defaults write com.apple.screencapture type -string "png"

# Disable shadow in screenshots
defaults write com.apple.screencapture disable-shadow -bool true

# Enable subpixel font rendering on non-Apple LCDs
defaults write NSGlobalDomain AppleFontSmoothing -int 2

# Enable HiDPI display modes (requires restart)
sudo defaults write /Library/Preferences/com.apple.windowserver DisplayResolutionEnabled -bool true

###############################################################################
# Finder #
###############################################################################

# Finder: allow quitting via ⌘ + Q; doing so will also hide desktop icons
defaults write com.apple.finder QuitMenuItem -bool true

# Finder: disable window animations and Get Info animations
defaults write com.apple.finder DisableAllAnimations -bool true

# Show icons for hard drives, servers, and removable media on the desktop
defaults write com.apple.finder ShowExternalHardDrivesOnDesktop -bool true
defaults write com.apple.finder ShowHardDrivesOnDesktop -bool true
defaults write com.apple.finder ShowMountedServersOnDesktop -bool true
defaults write com.apple.finder ShowRemovableMediaOnDesktop -bool true

# Finder: show hidden files by default
defaults write com.apple.Finder AppleShowAllFiles -bool true

# Finder: show all filename extensions
defaults write NSGlobalDomain AppleShowAllExtensions -bool true

# Finder: show status bar
defaults write com.apple.finder ShowStatusBar -bool true

# Finder: allow text selection in Quick Look
defaults write com.apple.finder QLEnableTextSelection -bool true

# Display full POSIX path as Finder window title
defaults write com.apple.finder _FXShowPosixPathInTitle -bool true

# Disable the warning when changing a file extension
defaults write com.apple.finder FXEnableExtensionChangeWarning -bool false

# Avoid creating .DS_Store files on network volumes
defaults write com.apple.desktopservices DSDontWriteNetworkStores -bool true

# Disable disk image verification
defaults write com.apple.frameworks.diskimages skip-verify -bool true
defaults write com.apple.frameworks.diskimages skip-verify-locked -bool true
defaults write com.apple.frameworks.diskimages skip-verify-remote -bool true

# Automatically open a new Finder window when a volume is mounted
defaults write com.apple.frameworks.diskimages auto-open-ro-root -bool true
defaults write com.apple.frameworks.diskimages auto-open-rw-root -bool true
defaults write com.apple.finder OpenWindowForNewRemovableDisk -bool true

# Show item info below icons on the desktop and in other icon views
/usr/libexec/PlistBuddy -c "Set :DesktopViewSettings:IconViewSettings:showItemInfo true" ~/Library/Preferences/com.apple.finder.plist
/usr/libexec/PlistBuddy -c "Set :FK_StandardViewSettings:IconViewSettings:showItemInfo true" ~/Library/Preferences/com.apple.finder.plist
/usr/libexec/PlistBuddy -c "Set :StandardViewSettings:IconViewSettings:showItemInfo true" ~/Library/Preferences/com.apple.finder.plist

# Enable snap-to-grid for icons on the desktop and in other icon views
/usr/libexec/PlistBuddy -c "Set :DesktopViewSettings:IconViewSettings:arrangeBy grid" ~/Library/Preferences/com.apple.finder.plist
/usr/libexec/PlistBuddy -c "Set :FK_StandardViewSettings:IconViewSettings:arrangeBy grid" ~/Library/Preferences/com.apple.finder.plist
/usr/libexec/PlistBuddy -c "Set :StandardViewSettings:IconViewSettings:arrangeBy grid" ~/Library/Preferences/com.apple.finder.plist

# Increase grid spacing for icons on the desktop and in other icon views
/usr/libexec/PlistBuddy -c "Set :DesktopViewSettings:IconViewSettings:gridSpacing 100" ~/Library/Preferences/com.apple.finder.plist
/usr/libexec/PlistBuddy -c "Set :FK_StandardViewSettings:IconViewSettings:gridSpacing 100" ~/Library/Preferences/com.apple.finder.plist
/usr/libexec/PlistBuddy -c "Set :StandardViewSettings:IconViewSettings:gridSpacing 100" ~/Library/Preferences/com.apple.finder.plist

# Increase the size of icons on the desktop and in other icon views
/usr/libexec/PlistBuddy -c "Set :DesktopViewSettings:IconViewSettings:iconSize 80" ~/Library/Preferences/com.apple.finder.plist
/usr/libexec/PlistBuddy -c "Set :FK_StandardViewSettings:IconViewSettings:iconSize 80" ~/Library/Preferences/com.apple.finder.plist
/usr/libexec/PlistBuddy -c "Set :StandardViewSettings:IconViewSettings:iconSize 80" ~/Library/Preferences/com.apple.finder.plist

# Disable the warning before emptying the Trash
defaults write com.apple.finder WarnOnEmptyTrash -bool false

# Empty Trash securely by default
defaults write com.apple.finder EmptyTrashSecurely -bool true

# Enable AirDrop over Ethernet and on unsupported Macs running Lion
defaults write com.apple.NetworkBrowser BrowseAllInterfaces -bool true

# Show the ~/Library folder
chflags nohidden ~/Library

# Remove Dropbox’s green checkmark icons in Finder
file=/Applications/Dropbox.app/Contents/Resources/check.icns
[ -e "$file" ] && mv -f "$file" "$file.bak"
unset file

###############################################################################
# Dock & hot corners #
###############################################################################

# Enable highlight hover effect for the grid view of a stack (Dock)
defaults write com.apple.dock mouse-over-hilte-stack -bool true

# Set the icon size of Dock items to 36 pixels
defaults write com.apple.dock tilesize -int 36

# Enable spring loading for all Dock items
defaults write com.apple.dock enable-spring-load-actions-on-all-items -bool true

# Show indicator lights for open applications in the Dock
defaults write com.apple.dock show-process-indicators -bool true

# Don’t animate opening applications from the Dock
defaults write com.apple.dock launchanim -bool false

# Speed up Mission Control animations
defaults write com.apple.dock expose-animation-duration -float 0.1

# Don’t group windows by application in Mission Control
# (i.e. use the old Exposé behavior instead)
defaults write com.apple.dock "expose-group-by-app" -bool false

# Don’t show Dashboard as a Space
defaults write com.apple.dock "dashboard-in-overlay" -bool true

# Remove the auto-hiding Dock delay
defaults write com.apple.Dock autohide-delay -float 0
# Remove the animation when hiding/showing the Dock
defaults write com.apple.dock autohide-time-modifier -float 0

# Enable the 2D Dock
#defaults write com.apple.dock no-glass -bool true

# Automatically hide and show the Dock
defaults write com.apple.dock autohide -bool true

# Make Dock icons of hidden applications translucent
defaults write com.apple.dock showhidden -bool true

# Enable iTunes track notifications in the Dock
defaults write com.apple.dock itunes-notifications -bool true

# Reset Launchpad
find ~/Library/Application\ Support/Dock -name "*.db" -maxdepth 1 -delete

# Add a spacer to the left side of the Dock (where the applications are)
#defaults write com.apple.dock persistent-apps -array-add '{tile-data={}; tile-type="spacer-tile";}'
# Add a spacer to the right side of the Dock (where the Trash is)
#defaults write com.apple.dock persistent-others -array-add '{tile-data={}; tile-type="spacer-tile";}'

# Hot corners
# Top left screen corner → Mission Control
defaults write com.apple.dock wvous-tl-corner -int 2
defaults write com.apple.dock wvous-tl-modifier -int 0
# Top right screen corner → Desktop
defaults write com.apple.dock wvous-tr-corner -int 4
defaults write com.apple.dock wvous-tr-modifier -int 0
# Bottom left screen corner → Start screen saver
defaults write com.apple.dock wvous-bl-corner -int 5
defaults write com.apple.dock wvous-bl-modifier -int 0

###############################################################################
# Safari & WebKit #
###############################################################################

# Allow hitting the Backspace key to go to the previous page in history
defaults write com.apple.Safari com.apple.Safari.ContentPageGroupIdentifier.WebKit2BackspaceKeyNavigationEnabled -bool true

# Hide Safari’s bookmarks bar by default
defaults write com.apple.Safari ShowFavoritesBar -bool false

# Disable Safari’s thumbnail cache for History and Top Sites
defaults write com.apple.Safari DebugSnapshotsUpdatePolicy -int 2

# Enable Safari’s debug menu
defaults write com.apple.Safari IncludeInternalDebugMenu -bool true

# Make Safari’s search banners default to Contains instead of Starts With
defaults write com.apple.Safari FindOnPageMatchesWordStartsOnly -bool false

# Remove useless icons from Safari’s bookmarks bar
defaults write com.apple.Safari ProxiesInBookmarksBar "()"

# Enable the Develop menu and the Web Inspector in Safari
defaults write com.apple.Safari IncludeDevelopMenu -bool true
defaults write com.apple.Safari WebKitDeveloperExtrasEnabledPreferenceKey -bool true
defaults write com.apple.Safari "com.apple.Safari.ContentPageGroupIdentifier.WebKit2DeveloperExtrasEnabled" -bool true

# Add a context menu item for showing the Web Inspector in web views
defaults write NSGlobalDomain WebKitDeveloperExtras -bool true

###############################################################################
# Address Book, Dashboard, iCal, iTunes, Mail, and Disk Utility #
###############################################################################

# Enable the debug menu in Address Book
defaults write com.apple.addressbook ABShowDebugMenu -bool true

# Enable Dashboard dev mode (allows keeping widgets on the desktop)
defaults write com.apple.dashboard devmode -bool true

# Enable the debug menu in iCal
defaults write com.apple.iCal IncludeDebugMenu -bool true

# Make the iTunes arrow links go to your library instead of the iTunes Store
defaults write com.apple.iTunes invertStoreLinks -bool true

# Disable the iTunes arrow links completely
defaults write com.apple.iTunes show-store-arrow-links -bool false

# Disable the Ping sidebar in iTunes
defaults write com.apple.iTunes disablePingSidebar -bool true

# Disable all the other Ping stuff in iTunes
defaults write com.apple.iTunes disablePing -bool true

# Make ⌘ + F focus the search input in iTunes
defaults write com.apple.iTunes NSUserKeyEquivalents -dict-add "Target Search Field" "@F"

# Disable send and reply animations in Mail.app
defaults write com.apple.Mail DisableReplyAnimations -bool true
defaults write com.apple.Mail DisableSendAnimations -bool true

# Copy email addresses as [email protected]` instead of `Foo Bar ` in Mail.app
defaults write com.apple.mail AddressesIncludeNameOnPasteboard -bool false

# Enable the debug menu in Disk Utility
defaults write com.apple.DiskUtility DUDebugMenuEnabled -bool true

###############################################################################
# Terminal #
###############################################################################

# Only use UTF-8 in Terminal.app
defaults write com.apple.terminal StringEncodings -array 4

# Use a modified version of the Pro theme by default in Terminal.app
open "$HOME/init/Mathias.terminal"
sleep 1 # Wait a bit to make sure the theme is loaded
defaults write com.apple.Terminal "Default Window Settings" -string "Mathias"
defaults write com.apple.Terminal "Startup Window Settings" -string "Mathias"

# Enable “focus follows mouse” for Terminal.app and all X11 apps
# This means you can hover over a window and start typing in it without clicking first
#defaults write com.apple.terminal FocusFollowsMouse -bool true
#defaults write org.x.X11 wm_ffm -bool true

###############################################################################
# Time Machine #
###############################################################################

# Prevent Time Machine from prompting to use new hard drives as backup volume
defaults write com.apple.TimeMachine DoNotOfferNewDisksForBackup -bool true

# Disable local Time Machine backups
hash tmutil &> /dev/null && sudo tmutil disablelocal

###############################################################################
# Twitter.app #
###############################################################################

# Disable smart quotes as it’s annoying for code tweets
defaults write com.twitter.twitter-mac AutomaticQuoteSubstitutionEnabled -bool false

# Show the app window when clicking the menu icon
defaults write com.twitter.twitter-mac MenuItemBehavior -int 1

# Enable the hidden ‘Develop’ menu
defaults write com.twitter.twitter-mac ShowDevelopMenu -bool true

# Open links in the background
defaults write com.twitter.twitter-mac openLinksInBackground -bool true

# Allow closing the ‘new tweet’ window by pressing `Esc`
defaults write com.twitter.twitter-mac ESCClosesComposeWindow -bool true

# Show full names rather than Twitter handles
defaults write com.twitter.twitter-mac ShowFullNames -bool true

# Hide the app in the background if it’s not the front-most window
defaults write com.twitter.twitter-mac HideInBackground -bool true

###############################################################################
# Kill affected applications #
###############################################################################

for app in Finder Dock Mail Safari iTunes iCal Address\ Book SystemUIServer Twitter; do
killall "$app" > /dev/null 2>&1
done
echo "Done. Note that some of these changes require a logout/restart to take effect."

SSH to your remote machine using Back to My Mac iCloud Service

datePosted on 14:14, July 27th, 2012 by Many Ayromlou

This is kinda cool. It only works if you have access to “Back to My Mac” service and you have it turned on in the remote mac’s preferences (under iCloud preferences). If you ever need to find out the FQDN (Fully Qualified Domain Name) of your remote mac and connect to it via ssh or something like it you can use the following command in the terminal:

echo show Setup:/Network/BackToMyMac | scutil | sed -n 's/.* : *\(.*\).$/\1/p'

This should spit out the “domain name” for your “personal” iCloud DNS. The output looks something like this:

12345678.members.btmm.icloud.com

To use this in a ssh command you would need the name of the remote machine plus the information above:

ssh -2 -6 remote-hostname.12345678.members.btmm.icloud.com

That’s it…..you should see a prompt for ssh login to your remote machine.

Synology NAS and those pesky @eaDir folders

datePosted on 20:22, March 8th, 2012 by Many Ayromlou

If you’ve enabled MediaServer and/or PhotoStation on your Synology NAS you might have noticed a bunch of “@eaDir” folders inside your data folders. You will not normally see this under samba or appletalk connections. I noticed it since I was trying to rsync from synology to a old qnap nas I have lying around. Although you can turn these services off from the Control Panel, it does not get rid of these dumb folders. So here is a quick script to clean all the “@eaDir” folders up from your synology disk. NOTE: I’VE INTENTIONALLY NOT USED THE “rm -rf” COMMAND HERE. I DON’T WANT YOU TO DESTROY YOUR NAS SERVER WITH JUST ONE COMMAND. Run the command below and it will “echo” the names of these “@eaDir” folders to the terminal. Then once you’re satistied that it’s working well (no weird filenames/characters/etc.), then replace the “echo” with “rm -rf” to actually remove those folders. There is no guarantee that this will work for you, DO NOT USE THIS IF YOU DON’T UNDERSTAND WHAT THE COMMAND DOES. THIS CAN HARM YOUR FILES.

find . -name "@eaDir" -type d -print |while read FILENAME; do echo "${FILENAME}"; done

Make sure you login via ssh first and “cd” to where your files are stored. This command starts looking for “@eaDir” folders recursively from the current directory.

Stream your Windows desktop using ffmpeg

datePosted on 10:26, November 3rd, 2011 by Many Ayromlou

I’ve already covered how to do this with vlc a while back in parts 1 followed by part 2. I just found out that something very similar in results can be done with ffmpeg. ffmpeg has recently added support for directshow filters which now allows one to capture the screen and stream and/or save it. Here is how you can do this:

1.) Grab a copy of the Screen Capture DirectShow source filter from Unreal Streaming Technologies. It’s about half way down that page. They have both the UScreenCapture X86 Edition and the X64 Edition (depending on your OS installation). I used the 64 bit filter on a Windows 7 64 bit installation.

2.) Install the filter and make sure you make the following changes to your windows registry using regedit. The default frame rate for UScreenCapture filter is 10 f/s and we need to boost this to 30 frames/sec. You need to find the key HKLM\SOFTWARE\UNREAL\Live\UScreenCapture and insert a DWORD value of 30 for FrameRate (You have to create FrameRate, it does not exist by default). Once you’ve done the registry tweak, reboot.

3.) Install the latest greatest version of ffmpeg for your windows version from Zeranoe. I grabbed the 64 bit Static build since I didn’t want to deal with libraries and such. Extract it and stick it somewhere on your hard drive. Remember the path to this folder since we will need it later.

4.) Open a command line window and cd to the directory where you extracted ffmpeg into, find the bin directory and cd into it. This is were the ffmpeg executable resides. In my case (I extracted the ffmpeg files into “Program Files” directory) it is C:\Program Files\ffmpeg-git-059707e-win64-static\bin.

5.) If you’ve made it this far, hand in there, we’re almost home. Now you need to issue the command that gets the screen streaming going. But first we need to find out the name of the Screen filter device. So issue the following command:

ffmpeg -list_devices true -f dshow -i dummy

In the output look for a device called “UScreenCapture“. Hopefully if everything is working with the directshow filter you have a entry in the list. That’s the name of our device that we need to pass onto ffmpeg. While you’re there also look for your audio device entry as well. Mine was the truncated word “Stereo Mix (Realtek High Defini” (Yes mine was missing the end of that line). Jot that down somewhere as well. I will show you how to get audio going as well.

6.) So first step is to get video going. Assuming you have a “UScreenCapture” device (You could use another directshow filter if you like, this will work with most of them. I just used the Unreal filter for the heck of it), here is the command to start encoding and sending video:

ffmpeg -f dshow  -i video="UScreenCapture"  -r 30 -vcodec mpeg4 -q 12 -f mpegts udp://aaa.bbb.ccc.ddd:6666?pkt_size=188?buffer_size=65535
  • -f dshow specifies that you’re going to be using a directshow device as your input.
  • -i video=”UScreenCapture” is the name of the input directshow device which we picked up in step 5.
  • -r 30 is the frame rate.
  • -vcodec mpeg4 is our video codec of choice.
  • -q 12 is a quality measure for the encoding process (1 is the best and 30 the worst). We’re doing VBR encoding so this measures the compression ratio vs. picture quality.
  • -f mpegts is our output filetype. In this case mpeg-2 transport stream. Yes, we’re encapsulating mpeg4 video inside a mpeg-2 transport stream…..why?….google it.
  • udp://aaa.bbb.ccc.ddd:6666?pkt_size=188?buffer_size=65535 this last bit specifies the address and port number of the recipient machine (aaa.bbb.ccc.ddd is the ip address of that machine and 6666 is my arbitrary port number). We’re also instructing ffmpeg to create smaller 188 byte size udp packets (which is the size of the transport stream packets) to decrease latency and our buffer size is 64kb.

7.) On the receiving machine you should be able to use vlc, ffmpeg or mplayer to catch the stream. In vlc simply open the Network stream rtp://@:6666 , in ffmpeg you can use the command ffplay -i udp://:6666 or using mplayer you can issue the command mplayer -framedrop -double udp://:6666 .

8.) Now to optionally add sound to the whole thing we can use this command on the encoding machine (instead of step 6). You need to know the device name for your sound card and you probably want to turn the volume down (at least initially) on the decoding machine.

ffmpeg -f dshow  -i video="UScreenCapture" -f dshow -i audio="Stereo Mix (Realtek High Defini" -r 30 -vcodec mpeg4 -q 20 -acodec libmp3lame -ab 128k -f mpegts udp://141.117.224.74:6666?pkt_size=188?buffer_size=65535
  • -f dshow specifies that you’re going to be using a directshow device as your input (VIDEO).
  • -i video=”UScreenCapture” is the name of the input directshow video device which we picked up in step 5.
  • -f dshow specifies that you’re going to be using a directshow device as your input (AUDIO).
  • -i audio=”Stereo Mix (Realtek High Defini” is the name of the input directshow audio device which we picked up in step 5.
  • -r 30 is the frame rate.
  • -vcodec mpeg4 is our video codec of choice.
  • -q 20 is a quality measure for the encoding process (1 is the best and 30 the worst). We’re doing VBR encoding so this measures the compression ratio vs. picture quality. I went with 20 instead of 12 from step 6 since the audio encoding slows the machine down a bit.
  • -acodec libmp3lame is our video codec of choice
  • -f mpegts is our output filetype. In this case mpeg-2 transport stream. Yes, we’re encapsulating mpeg4 video inside a mpeg-2 transport stream…..why?….google it.
  • udp://aaa.bbb.ccc.ddd:6666?pkt_size=188?buffer_size=65535 this last bit specifies the address and port number of the recipient machine (aaa.bbb.ccc.ddd is the ip address of that machine and 6666 is my arbitrary port number). We’re also instructing ffmpeg to create smaller 188 byte size udp packets (which is the size of the transport stream packets) to decrease latency and our buffer size is 64kb.
123456Next
